Aggregate Bin Feeders

• Equipment Type
• Aggregate Feeder

• Attributes
• Strong, Durable, Rust Proof, Consume Less Power, Easy To Operate

• Belt Type
• 4 ply

• Color
• Grey

• Condition
• New

• Control System
• PLC

• Feature
• Individually controlled bins, adjustable belt feeders, easy material flow

• Features
• Accurate aggregate feeding Variable speed belt control Heavy-duty MS construction Adjustable discharge gates Low maintenance design Uniform material flow to dryer drum PLC automation compatible

• Forklift
• NA

• Handle Type
• NA

• Height
• 8.6 Foot (ft)

• Length
• 40 Foot (ft)

• Length of Belt
• 25.9 Meter (m)

• Lifting Capacity
• NA Gram (g)

• Lifting Speed
• NA mm/s

• Max. Lifting Height
• NA Inch (in)

• Max. Lifting Load
• NA Gram (g)

• Motor Type
• 5 HP

• Power Source
• Electric

• Product Type
• Cold Aggregate Bin Feeders

• Rack Capacity
• NA Cubic Meter (m3)

• Rotation Type
• NA

• Size
• Standard Industrial Size

• Usage
• Industrial Areas, Roads, Factories, Warehouses

• Voltage
• 380 - 440 Volt (v)

• Warranty
• Yes

• Weight
• 8000 Kilograms (kg)

• Width
• 7.6 Foot (ft)

• Equipment Type
• Feeder unit with multiple aggregate bins

• Attributes
• Durable, Strong

• Belt Type
• Endless rubber conveyor belt with rollers & idlers

• Color
• Yellow

• Condition
• New

• Control System
• Centralized control with variable frequency drive (VFD) for precise proportioning

• Feature
• Individually controlled bins, adjustable belt feeders, easy material flow

• Features
• Sturdy, maintenance-friendly, ensures consistent aggregate flow

• Forklift
• NA

• Handle Type
• NA

• Height
• 3-4.5 Meter (m)

• Length
• 8-12 Meter (m)

• Length of Belt
• Customizable (typically 600 mm 800 mm wide, length as per capacity) Meter (m)

• Lifting Capacity
• up to 200 TPH depending on plant model Metric Ton

• Lifting Speed
• Belt speed 0.5 1.5 m/sec (variable speed drive) m/s

• Max. Lifting Height
• NA Meter (m)

• Max. Lifting Load
• 60 250 TPH (depending on model) Metric Ton

• Motor Type
• TEFC (Totally Enclosed Fan-Cooled) electric motors

• Power Consumption
• 5 15 HP per bin depending on size Horsepower (HP)

• Power Source
• Electric

• Product Type
• Aggregate Bin Feeders

• Rack Capacity
• NA Kilogram(Kg)

• Rotation Type
• Belt-driven continuous feed

• Size
• Capacity-based (60 TPH, 100 TPH, 160 TPH, 200 TPH, 250,300 TPH models)

• Usage
• Feeding and proportioning aggregates in asphalt drum/batch mix and WMM plants

• Voltage
• 415 Volt (v)

• Warranty
• Yes

• Weight
• Varies with model (8 15 Tons approx.) Kilograms (kg)

• Wheel Type
• Rubber

• Width
• 2.5-3.5 Meter (m)

• Equipment Type
• Cold Bin Aggregate Feeder

• Belt Type
• 2-ply rubber belting is standard.

• Color
• Grey

• Condition
• New

• Control System
• Manual/Automatic:

• Feature
• Reinforced top lip and horizontal angle steel reinforcements. Adjustable discharge gates with a hand crank for precise material flow control. Self-relieving tapered hopper bottoms to minimise material bridging. Skirtboards with adjustable rubber flashing to prevent leakage. Premium efficiency motors for variable frequency drives (VFDs). Heavy-duty belt feeders with 2-ply rubber belting

• Features
• Heavy-duty construction for durability. Adjustable discharge gates for precise material flow. Self-cleaning components to reduce maintenance. Compatibility with various aggregate types.

• Forklift
• NA

• Handle Type
• Hand crank for manual discharge gate adjustment

• Height
• 10 to 14 Foot (ft)

• Length
• 8 to 16 Foot (ft)

• Length of Belt
• 8 to 19.5 feet, depending on the model Foot (ft)

• Lifting Capacity
• 18 to 60 Metric Ton

• Lifting Speed
• NA Km/s

• Max. Lifting Height
• Not applicable Meter (m)

• Max. Lifting Load
• 40 tons, depending on the model and configuration. Tonne

• Motor Type
• Premium efficiency electric motors

• Power Consumption
• 5 to 15 HP, depending on the feeder's size and capacity. Horsepower (HP)

• Power Source
• Electric

• Product Type
• Cold Aggregate Bin Feeders

• Rack Capacity
• NA Kilogram(Kg)

• Rotation Type
• NA

• Size
• Standard

• Usage
• Industrial

• Voltage
• 460 Volt (v)

• Warranty
• Yes

• Weight
• weight varies based on configuration Kilograms (kg)

• Wheel Type
• Rubber

• Width
• 6.5 to 12 Foot (ft)
